Product Description
DIMENSIONS:
- Outside: 6 3/8 x 4 3/8 x 4 5/8" (+/- 1/8")
- All FedEx and all UPS Dimensional Weight: 1 lb
MATERIAL:
- All 200# kraft test boxes are C flute except:
- B flute:
- S-13287 (3 x 3 x 3")
- S-16725 (4 x 4 x 3")
- S-4040 (4 x 4 x 4")
- S-19037 (4 x 4 x 5")
- S-4050 (5 x 5 x 5")
- B flute:
FEATURES:
- All boxes open along the length (first dimension).
- Seams are glued.
SPECIFICATIONS:
- Meets ASTM D5118
TERMINOLOGY:
- 200# Test vs 32 ECT (Edge Crush Test):
- 200# Test:
- 60% stronger bursting strength.
- Recommended by UPS for shipping up to 40 lbs.
- 32 ECT:
- Recommended by UPS for shipping up to 30 lbs.
- 200# Test:
- Pound Test Refers to Bursting Strength:
- 200# test boxes withstand 200 lbs/sq.in. of side wall pressure before bursting.
- ECT Refers to Stacking Strength:
- 32 ECT boxes withstand 32 lbs/linear inch of stacking weight before crushing.
- An alternative for lightweight shipments.
BOX STRENGTH GUIDELINES: (Maximum weight per box)
| FIBER BOX HANDBOOK | UPS GUIDELINES | |
| 32 ECT Single Wall | 65 lbs | 30 lbs |
| 200# Single Wall | 65 lbs | 40 lbs |
| 275# Single Wall | 95 lbs | 65 lbs |
| 350# Single Wall | 120 lbs | 80 lbs |
| 200# Double Wall | 80 lbs | 60 lbs |
| 275# Double Wall | 100 lbs | 80 lbs |
| 350# Double Wall | 120 lbs | 100 lbs |
| 500# Double Wall | 160 lbs | 140 lbs |
Product Videos
Custom Field
Bundle Quantity Sold in bundles of 25 ea.
Interval Quantity 25
